纽荷兰零件查询(DC80) - CRAWLER DOZER (N.A. VERSION) (4/99-) (9.240[02B]) - TRACK CHAIN (L=610 MM) LGP DC80 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9. | 76590784 | [4] | SCREW | MAC |
| 10. | 76590785 | [156] | SCREW | MAC |
| 11. | 76590786 | [1] | CONNECTING LINK | MACLink, Chain Master RH |
| 12. | 76590787 | [1] | TRACK LINK | MACLink, Chain Master LH |
| 13. | 76590788 | [156] | NUT | MAC |
| 14. | 76593261 | [1] | KIT | MACPin/Bushing |
| 25. | CHAIN | [1] | CHAIN | FORAssy Superseded by part number: 76590799 |
| 26. | 76598795 | [2] | TRACK ASSY | MACTrack Assy with Pad |
| 27. | 76593308 | [1] | TRACK SHOE | MACMaster Shoe |
| 28. | 76593268 | [38] | TRACK SHOE | MAC |
![]()
