| 2. | L113522 | [4] | SEAL | CASUse Loctite No. 271 |
| . . | B17500 | [1] | LOCTITE | CASNo. 271, 6 ml Superseded by part number: ZPX27110 |
| 3. | 405608A1 | [2] | PIN,63.6mm OD x 183mm L | BUR |
| 4. | 419041A1 | [4] | SPACER | BUR |
| 6. | 435157A1 | [1] | GROOVED PIN,44.42mm OD x 165mm L | BURRod End; Tilt Cylinder |
| 7. | 627-16025 | [6] | BOLT,Hex, M16 x 2 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86639032 |
| 7A. | 627-16035 | [2] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86529976 |
| 8. | 627-16050 | [4] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | CAS Superseded by part number: 412398 |
| 10. | 495-81283 | [6] | WASHER,2 5/8" x 4" x .109" | BRR2-9/16 x 4 x 1/8; Used As A Shim |
| 12. | 419223A1 | [12] | WASHER | BUR |
| 14. | 419205A1 | [2] | PIN | BURClosed End; Angle Cylinder |
| 15. | 405607A1 | [2] | GROOVED PIN,44.42mm OD x 165mm L | BURLift Cylinder |
| 17. | 87345907 | [1] | FRAME ASSY | BURIncl. Ref 18 - 20; Replaces 87434530 Superseded by part number: 87345907A |
| 18. | D33635 | [4] | BUSHING,63.75mm ID x 76.2mm OD x 25.4mm L | CAS2-1/2 x 3 x 1 |
| 20. | D43940 | [2] | BUSHING,44.68mm ID x 57.15mm OD x 25.4mm L | CAS1-3/4 x 2-1/4 x 1 |
| 21. | 86981867 | [2] | CYLINDER ASSY.,Double Acting, 44.4mm Rod, 394.5mm Stroke | BUR89 ID x 395 mm Stroke; Lift; See Figure 08-11 Superseded by part number: 87361535 |
| 21. | 87361535R | [2] | REMAN-HYD CYLINDER | BURDC75 (8/04), Reman For New P/N 86981867 |
| 21. | 87361535C | [2] | CORE-HYD CYLINDER | BURReturn Number |
| 22. | 87432203 | [1] | CYLINDER ASSY.,Double Acting, 44.4mm Rod, 147.8mm Stroke | BUR89 ID x 148 mm Stroke; Tilt; See Figure 08-12 |
| 23. | 87615547 | [2] | CYLINDER ASSY. | BURReplaces 87432198; 89 ID x 396 mm Stroke; Angle; See Figure 08-13 Superseded by part number: 84135900 |
| 23. | 84135900R | [2] | REMAN-HYD CYLINDER | BURReman for New PN 87615547 |
| 23. | 84135900C | [2] | CORE-HYD CYLINDER | BURReturn Number |
| 24. | 345410A1 | [2] | GROOVED PIN | BURLift Cylinder |
| 25. | 414988A1 | [10] | SHIM | BURLGP Models; If Used |
| 26. | 814-12110 | [4] | BOLT,Hex, M12 x 1.75 x 110mm, Cl 8.8 | CASUse Loctite No. 243; LGP Models Superseded by part number: 86562594 |
| 27. | 895-11012 | [4] | WASHER,13.5mm ID x 24mm OD x 2.5mm Thk | CAS |
| 28. | 414987A1 | [2] | WEAR PLATE | BUR |
| 29. | 814-12100 | [4] | BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8 | IHM12 x 100; Use Loctite No. 243 Superseded by part number: 374887 |
