纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (9.240[02A]) - TRACK CHAIN (L=560MM) LGP DC70 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10. | 76598661 | [172] | SCREW | MAC Superseded by part number: 5117440 |
| 11. | 76598785 | [1] | PIN | MAC |
| 12. | 76598786 | [1] | BUSHING | MAC |
| 13. | 76598664 | [172] | NUT | MAC Superseded by part number: 5117441 |
| 14. | 76598787 | [1] | LINK CHAIN | MACKit Superseded by part number: 75128927, 75128925, 76598786, 76598785, 75128924, 75128926 |
| 25. | 76598788 | [1] | CHAIN | MAC Superseded by part number: 76598684 |
| 26. | 76598790 | [2] | TRACK ASSY | MAC Superseded by part number: 76598781 |
| 28. | 76598789 | [38] | TRACK SHOE | MAC Superseded by part number: 76598783 |
| 29. | 76598266 | [20] | LOCK WASHER | MAC Superseded by part number: 11194274 |
![]()
