现代零件查询R110-7A SINGLE PEDAL(DOUBLE ACTING)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
34E7-04720
|
[1] |
PEDAL-SINGLE
|
|
| 1. |
J24D2001
|
[1] |
CASE
|
|
| 2. |
J24D2002
|
[1] |
PEDAL
|
|
| 3. |
J24D2003
|
[1] |
COVER-PEDAL
|
|
| 4. |
J24D2004
|
[1] |
COVER
|
|
| 5. |
DU1010
|
[2] |
BUSHING
|
|
| 6. |
J24D2005
|
[1] |
CAM
|
|
| 7. |
J24D2006
|
[1] |
BELLOWS
|
|
| 8. |
J24D2007
|
[2] |
SPOOL
|
|
| 9. |
S090601
|
[2] |
SHIM(1.0T)
|
|
| 10. |
J24D2008
|
[2] |
SEAT-SPRING
|
|
| 11. |
J97C1001
|
[2] |
SPRING
|
|
| 12. |
J24D2010
|
[2] |
SEAT-SPRING
|
|
| 13. |
J24D2011
|
[2] |
STOPPER
|
|
| 14. |
J24D2012
|
[2] |
PLUG
|
|
| 15. |
PO020
|
[2] |
O-RING
|
|
| 16. |
DSP10
|
[2] |
SEAL-DUST
|
|
| 17. |
RSY10
|
[2] |
SEAL-ROD
|
|
| 18. |
J98H2001
|
[2] |
SPRING
|
|
| 19. |
J24D2014
|
[2] |
ROD-PUSH
|
|
| 20. |
WBM0830
|
[2] |
BOLT-SOCKET
|
|
| 21. |
J24D2015
|
[2] |
SCREW-SET
|
|
| 22. |
HNM10
|
[2] |
NUT-HEX
|
|
| 23. |
J24D2016
|
[1] |
SHAFT-CAM
|
|
| 24. |
SBM0812
|
[1] |
SCREW-SET
|
|
| 25. |
WBM1015
|
[2] |
BOLT-SOCKET
|
|
| 26. |
J2J1002
|
[1] |
BLOCK
|
|
| 27. |
PO012
|
[2] |
O-RING
|
|
| 28. |
WBM0840
|
[2] |
BOLT-SOCKET
|
|
| 29. |
WPT38
|
[1] |
PLUG
|
|
| 30. |
WPT18
|
[1] |
PLUG
|
|
![]()
