现代零件查询R110-7 TRAVEL HYD PIPING(DOZER BLADE 2)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 9. |
P913-067037
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 10. |
P933-067039
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 11. |
P913-047050
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 17. |
X820-085252
|
[2] |
TEE-R/TYPE,ORFS
|
|
| 18. |
X520-110002
|
[4] |
ELBOW-90,ORFS
|
|
| 19. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 26. |
S621-012001
|
[8] |
O-RING,ORFS
|
|
| 27. |
S621-011001
|
[2] |
O-RING,ORFS
|
|
| 29. |
S631-014004
|
[4] |
O-RING
|
|
| 30. |
S631-014004
|
[4] |
O-RING
|
|
| 31. |
S631-011004
|
[4] |
O-RING
|
|
| 34. |
S760-082012
|
[1] |
GROMMET
|
|
| 40. |
31E4-3146
|
[4] |
STRAP
|
|
| 41. |
S035-081522
|
[8] |
BOLT-W/WASHER
|
|
| 42. |
P220-110102
|
[2] |
PLUG-HEX
|
|
![]()
