现代零件查询R110-7 TRAVEL HYD PIPING(DOZER BLADE 1)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
31N1-40970
|
[1] |
GASKET
|
|
| 6. |
P950-127330
|
[4] |
HOSE ASSY-ORFS,FLG 0X45
|
|
| 7. |
P920-082031
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 8. |
P930-042036
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P930-042039
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 12. |
X500-310004
|
[4] |
CONNECTOR-ORFS
|
|
| 13. |
X500-310003
|
[2] |
CONNECTOR-ORFS
|
|
| 14. |
31N5-10420
|
[2] |
CONNECTOR-LONG
|
|
| 14. |
X500-310001
|
[2] |
CONNECTOR-ORFS
|
|
| 15. |
X810-085353
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 16. |
X810-065151
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 20. |
P173-120102
|
[8] |
FLANGE-HYD,SPLIT
|
|
| 21. |
S611-023001
|
[4] |
O-RING
|
|
| 22. |
S611-016001
|
[2] |
O-RING
|
|
| 23. |
S611-009001
|
[2] |
O-RING
|
|
| 24. |
S621-018001
|
[4] |
O-RING
|
|
| 25. |
S621-014001
|
[4] |
O-RING
|
|
| 27. |
S621-011001
|
[4] |
O-RING
|
|
| 28. |
Y171-019001
|
[4] |
O-RING
|
|
| 29. |
S631-014004
|
[1] |
O-RING
|
|
| 30. |
S631-014004
|
[1] |
O-RING
|
|
| 32. |
S760-101221
|
[2] |
GROMMET
|
|
| 33. |
31E3-31230
|
[2] |
GROMMET
|
|
| 35. |
S017-160502
|
[32] |
BOLT-HEX
|
|
| 36. |
S109-100306
|
[16] |
BOLT-SOCKET
|
|
| 37. |
S037-123022
|
[4] |
BOLT-W/WASHER
|
|
| 38. |
S411-160002
|
[32] |
WASHER-SPRING
|
|
| 39. |
S552-102370
|
[6] |
CLAMP-BAND
|
|
![]()
