沃尔沃零件查询L40 Engine hood - FasteningTYPE 191, 192 SER NO - 10001910001-1920001NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZM2812845
|
[1] |
Hood Support
|
|
| 2. |
VOE983252
|
[7] |
Hexagon screw
|
|
| 3. |
VOE14370970
|
[7] |
Lock nut
|
M10
|
| 4. |
VOE930842
|
[7] |
Plain washer
|
10,5
|
| 5. |
ZM2812863
|
[1] |
Bracket
|
|
| 6. |
VOE983243
|
[2] |
Hexagon screw
|
M8x25
|
| 7. |
ZM7098010
|
[2] |
Nut
|
M8
|
| 8. |
VOE11305837
|
[2] |
Washer
|
B 8,4
|
| 9. |
ZM2812682
|
[2] |
Ferrule
|
|
| 10. |
ZM2812683
|
[2] |
Clamp segment
|
|
| 11. |
ZM2289003
|
[4] |
Screw
|
M5x16
|
| 12. |
VOE955780
|
[4] |
Hexagon nut
|
M5
|
| 13. |
ZM2802430
|
[4] |
Washer
|
2,0 mm
|
| 14. |
VOE11305892
|
[1] |
Wing screw
|
M10x25
|
| 15. |
ZM2813332
|
[2] |
Sliding block
|
|
| 16. |
VOE11305109
|
[4] |
Screw
|
|
| 17. |
ZM2812849
|
[1] |
Hood Bracket
|
|
| 18. |
VOE983252
|
[3] |
Hexagon screw
|
|
| 19. |
VOE930842
|
[6] |
Plain washer
|
10,5
|
| 20. |
VOE14370970
|
[3] |
Lock nut
|
M10
|
| 21. |
ZM5024150
|
[3] |
Buffer
|
|
| 22. |
VOE11305837
|
[10] |
Washer
|
B 8,4
|
| 23. |
ZM7098010
|
[10] |
Nut
|
M8
|
| 24. |
ZM2812866
|
[2] |
Holder
|
|
| 25. |
ZM2811626
|
[1] |
Holder
|
|
| 26. |
VOE983243
|
[2] |
Hexagon screw
|
M8x25
|
| 27. |
ZM7098010
|
[2] |
Nut
|
M8
|
| 28. |
VOE11305837
|
[2] |
Washer
|
B 8,4
|
| 29. |
ZM2813605
|
[1] |
Path plate
|
|
| 30. |
VOE983242
|
[5] |
Hexagon screw
|
M8x20
|
| 31. |
VOE11305837
|
[5] |
Washer
|
B 8,4
|
| 32. |
ZM2812123
|
[1] |
Edge protection
|
|
| 33. |
ZM2813604
|
[1] |
Holder
|
|
| 34. |
ZM2813331
|
[1] |
Holder
|
|
| 35. |
VOE983243
|
[2] |
Hexagon screw
|
M8x25
|
| 36. |
VOE11305837
|
[2] |
Washer
|
B 8,4
|
| 37. |
ZM7098010
|
[2] |
Nut
|
M8
|
| 38. |
ZM4378146
|
[4] |
Cam
|
|
| 39. |
ZM2091830
|
[4] |
Blind rivet
|
A3x8
|
| 40. |
ZM2813327
|
[1] |
Cover
|
|
| 41. |
VOE14370276
|
[2] |
Screw
|
M8x60
|
| 42. |
VOE983242
|
[3] |
Hexagon screw
|
M8x20
|
| 43. |
VOE11305837
|
[5] |
Washer
|
B 8,4
|
| 44. |
ZM7098010
|
[2] |
Nut
|
M8
|
| 45. |
VOE15072320
|
[1] |
Sealing moulding
|
L = 1200MM
|
| 46. |
ZM2813637
|
[1] |
Fan Protector
|
|
| 47. |
ZM8095500
|
[5] |
Screw
|
M8x12
|
| 48. |
ZM7098010
|
[5] |
Nut
|
M8
|
| 49. |
ZM2813329
|
[1] |
Cover
|
|
| 50. |
ZM2802329
|
[4] |
Locking Pin
|
|
| 51. |
VOE14371047
|
[4] |
Lock washer
|
|
| 52. |
VOE11305888
|
[1] |
Sealing strip
|
L = 200MM
|
| 53. |
ZM4416209
|
[1] |
Sponge rubber
|
|
| 54. |
ZM2813402
|
[1] |
Holder
|
|
| 55. |
ZM7098000
|
[2] |
Nut
|
M6
|
| 56. |
ZM4333068
|
[2] |
Washer
|
|
| 57. |
ZM2813399
|
[1] |
Bolt
|
|
| 58. |
VOE983304
|
[1] |
Hexagon nut
|
M10
|
| 59. |
VOE930842
|
[1] |
Plain washer
|
10,5
|
| 60. |
ZM2813332
|
[1] |
Sliding block
|
|
| 61. |
VOE11305109
|
[2] |
Screw
|
|
| 62. |
ZM7091355
|
[1] |
Yoke end
|
G8x16
|
| 63. |
VOE945634
|
[1] |
Yoke Bolt
|
8x16
|
| 64. |
VOE983242
|
[1] |
Hexagon screw
|
M8x20
|
| 65. |
ZM7098010
|
[2] |
Nut
|
M8
|
| 66. |
ZM4336055
|
[1] |
Eye
|
|
| 67. |
ZM2813606
|
[1] |
Hood Support
|
|
| 68. |
ZM2813607
|
[1] |
Holder
|
|
| 69. |
ZM7095370
|
[1] |
Screw
|
M8x16
|
| 70. |
ZM7098010
|
[1] |
Nut
|
M8
|
| 71. |
VOE11305886
|
[1] |
Clamp
|
|
| 72. |
ZM4328095
|
[1] |
Screw
|
M4x16
|
| 73. |
VOE955779
|
[1] |
Hexagon nut
|
M4
|
| 74. |
ZM2813330
|
[1] |
Spacer Sleeve
|
|
| 75. |
ZM7095952
|
[1] |
Bolt
|
M10x80
|
| 76. |
VOE14370970
|
[1] |
Lock nut
|
M10
|
| 77. |
VOE960148
|
[1] |
Plain washer
|
B10,5
|
| 78. |
VOE4398309
|
[1] |
Edge protection
|
L = 400MM
|
| 79. |
ZM2907668
|
[1] |
Sound Absorber
|
|
| 80. |
ZM2907669
|
[1] |
Sound Absorber
|
|
| 81. |
ZM2907670
|
[1] |
Damping material
|
|
| 82. |
ZM2907671
|
[2] |
Damping material
|
|
| 83. |
ZM2907672
|
[1] |
Damping material
|
|
| 84. |
ZM2809321
|
[2] |
Damper Mat
|
|
| 85. |
ZM2811424
|
[2] |
Spring clamp
|
|
| 86. |
ZM7096665
|
[4] |
Screw
|
M4x10
|
| 87. |
VOE955779
|
[4] |
Hexagon nut
|
M4
|
| 88. |
VOE11305886
|
[1] |
Clamp
|
|
| 89. |
ZM4328093
|
[1] |
Screw
|
M4x10
|
| 90. |
VOE955779
|
[1] |
Hexagon nut
|
M4
|
![]()
