纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (08-23) - VALVE ASSY, RELIEF New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | N8950 | [2] | VALVE | CASRelief Valve; Incl. Ref 1 - 15; Auxiliary/Ripper Section Upper and Lower Ports |
| 1. | D39716 | [2] | PLUG | CAS Superseded by part number: 517563 |
| 2. | 237-6010 | [1] | O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro | CAS Superseded by part number: 72186125, 167269 |
| 3. | N8196 | [1] | SPRING | CAS |
| 4. | N8190 | [1] | SLEEVE VALVE | CAS |
| 5. | A55893 | [1] | SHIM,.0418" Thk | CAS(1.016 mm) |
| 5. | A55894 | [1] | SHIM,.0209" Thk | CAS(0.508 mm) |
| 5. | D39712 | [1] | SHIM | CAS0,254 mm (0,01 in) |
| . . | 18-1417 | [1] | SEAL | CASIncl. Ref 6, 7 |
| 6. | NSS | [1] | NOT SERVICED SEPARATELY | CONPlunger |
| 7. | D39714 | [1] | RING | CASSeal |
| 10. | 238-6016 | [1] | O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro | CAS Superseded by part number: 9992069 |
| 11. | L35297 | [1] | RING,16.18mm ID x 19.07mm OD x 1.42mm Thk | CASBackup Superseded by part number: D0NNH947A |
| 12. | 238-5015 | [1] | O-RING,0.07" Thk x 0.551" ID, -15, Cl 5, 75 Duro | CAS Superseded by part number: 14453280 |
| 13. | D88725 | [2] | BACK-UP RING | CAS |
| 14. | H268730 | [1] | SPRING | CAS Superseded by part number: 527283 |
| 15. | D28576 | [1] | VALVE POPPET | CAS |
![]()
