纽荷兰零件查询(D180C WT/LGP) - CRAWLER DOZER - TIER 4A (12/13-) (55.680.AA[03]) - BLADE, GUIDE, LEICA READY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47408769 | [1] | BRACKET | BURLeica DZ Mast Bracket |
| 2. | 47408804 | [1] | BRACKET | BURLeica DZ Slope Sensor Bracket |
| 3. | 47408811 | [1] | WIRE HARNESS | BURLeica DZ Quick Connect Harness |
| 4. | 87423314 | [2] | GROMMET,1.5" ID x 2.125" ID x 0.562" Thk | EMLOil Cooler Grommet |
| 5. | 87035382 | [2] | CLAMP,30.2mm, Coat, 10.3mm Bolt Hole, P Type | GI |
| 6. | L11541 | [10] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 7. | 47408806 | [1] | BRACKET | BURLeica DZ Display Post Bracket |
| 8. | 47408796 | [1] | BRACKET | BURLeica DZ Display Arm Bracket |
| 9. | 47466115 | [1] | MODULE | BURLeica Cradle Module Superseded by part number: 47693937 |
| 10. | 47424058 | [1] | BRACKET | BURLeica DZ Controller Bracket |
| 11. | 47408808 | [1] | WIRE HARNESS | BURLeica DZ Interface Harness |
| 12. | 47466116 | [1] | MODULE | BURLeica Junction Box Module |
| 13. | 47422845 | [1] | WIRE HARNESS | BURLeica 1M Display Harness Superseded by part number: 47551349 |
| 14. | 47481723 | [1] | ELEC CONNECTOR | BURLeica Can Splitter Electronic Connector |
![]()
