纽荷兰零件查询(D180C LT) - CRAWLER DOZER - TIER 4A (12/13-) (55.680.AA[02]) - BLADE, GUIDE, TOPCON READY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47422701 | [1] | BRACKET | BURCenter Mast |
| 2. | 47422706 | [1] | BRACKET | BURSlope Sensor |
| 3. | 47422710 | [1] | BRACKET | BURQuick Connect |
| 4. | 47422687 | [1] | WIRE HARNESS | BURGPS BK |
| 5. | 47422684 | [1] | WIRE HARNESS | BURGPS YE |
| 6. | 87035382 | [6] | CLAMP,30.2mm, Coat, 10.3mm Bolt Hole, P Type | GI |
| 7. | 86624184 | [5] | WASHER,9mm ID x 16mm OD x 1.6mm Thk | FOR |
| 8. | 43139 | [5] | BOLT,M10 x 1.5 x 25mm, Cl 8.8 | NH Superseded by part number: 11106231, 11106231, BER43139 |
| 9. | L11541 | [18] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 10. | 47422711 | [1] | BRACKET | BURDisplay |
| 11. | 14442131 | [2] | SCREW,Flat Csk Hd, M8 x 1.25 x 25mm, Cl 10.9 | FOR Superseded by part number: 14442134 |
| 12. | 47422690 | [1] | WIRE HARNESS | BURInterface |
| 13. | 47422692 | [1] | WIRE HARNESS | BURSensor |
| 14. | 47422689 | [1] | WIRE HARNESS | BURRadio |
![]()
