现代零件查询R55W-7 DOZER BLADE CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
31M8-70010
|
[1] |
CYLINDER ASS'Y V/V
|
|
| *. |
31M8-70011
|
[1] |
DOZER CYLINDER ASSY
|
|
| 1. |
31Y1-22800
|
[1] |
TUBE ASSY
|
|
| 1. |
31Y1-22801
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-23740
|
[1] |
ROD ASSY
|
|
| 2. |
31Y1-23741
|
[1] |
ROD ASSY
|
|
| 3. |
31Y1-01170
|
[1] |
GLAND
|
|
| 4. |
S731-050030
|
[1] |
BUSHING-DU
|
|
| K5. |
Y210-050111
|
[1] |
SEAL-ROD
|
|
| K6. |
Y180-050120
|
[1] |
RING-BACK UP
|
|
| K7. |
Y110-050011
|
[1] |
WIPER-DUST
|
|
| 8. |
Y190-062000
|
[1] |
RING-SNAP
|
|
| K9. |
S632-100001
|
[1] |
O-RING
|
|
| K10. |
S632-095004
|
[1] |
O-RING
|
|
| K11. |
S642-096003
|
[1] |
RING-BACK UP
|
|
| 12. |
31Y1-24430
|
[1] |
PISTON
|
|
| K13. |
S632-040004
|
[1] |
O-RING
|
|
| K14. |
Y450-100000
|
[1] |
SEAL-PISTON
|
|
| K15. |
Y300-100100
|
[1] |
RING-WEAR
|
|
| 16. |
31YC-65290
|
[1] |
NUT-NYLON
|
|
| 17. |
31Y1-22850
|
[1] |
PIPE ASSY-R
|
|
| 17. |
31Y1-22851
|
[1] |
PIPE ASSY-R
|
|
| N18. |
31N6-70311
|
[1] |
CHECK VLV-DOUBLE,LH
|
|
| N18. |
31N6-75010
|
[1] |
CHECK VLV-DOUBLE
|
|
| K19. |
Y171-015004
|
[2] |
O-RING
|
|
| K20. |
S631-014004
|
[1] |
O-RING
|
|
| 21. |
S107-080404
|
[8] |
BOLT-SOCKET
|
|
| 22. |
S107-100654
|
[4] |
BOLT-SOCKET
|
|
| 23. |
31YC-12030
|
[2] |
BUSHING-PIN
|
|
| K24. |
Y010-055068
|
[4] |
SEAL-DUST
|
|
| 25. |
S652-810002
|
[1] |
NIPPLE-GREASE
|
|
| K. |
31Y1-24440
|
[1] |
SEAL KIT
|
|
