现代零件查询R140W-7A BUCKET CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| *. |
31N4-60110
|
[1] |
BUCKET CYLINDER
|
|
| *-1. |
31Y1-18180
|
[1] |
BUCKET CYL SUB ASSY
|
|
| 1. |
31Y1-03720
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-03770
|
[1] |
ROD ASSY
|
|
| 3. |
31Y1-19650
|
[1] |
GLAND
|
|
| 4. |
S732-070040
|
[1] |
BUSHING-DD2
|
|
| 5. |
Y191-076000
|
[1] |
RING-SNAP
|
|
| K6. |
Y220-070011
|
[1] |
SEAL-ROD
|
|
| K7. |
Y180-070020
|
[1] |
RING-BACK UP
|
|
| K8. |
Y240-070013
|
[1] |
RING-BUFFER
|
|
| K9. |
Y110-070011
|
[1] |
WIPER-DUST
|
|
| 10. |
Y190-084000
|
[1] |
RING-SNAP
|
|
| K11. |
S631-090004
|
[2] |
O-RING
|
|
| K12. |
S641-090002
|
[1] |
RING-BACK UP
|
|
| K13. |
S641-090003
|
[1] |
RING-BACK UP
|
|
| 14. |
31YC-21030
|
[1] |
RING-CUSHION
|
|
| 15. |
31Y1-03810
|
[1] |
PISTON
|
|
| K16. |
S632-060004
|
[1] |
O-RING
|
|
| K17. |
S642-060003
|
[2] |
RING-BACKUP,O-RING
|
|
| K18. |
Y420-100000
|
[1] |
SEAL-PISTON
|
|
| K19. |
Y310-100200
|
[2] |
RING-WEAR
|
|
| K20. |
Y440-100000
|
[2] |
RING-DUST
|
|
| 21. |
31YC-61020
|
[1] |
NUT-LOCK
|
|
| 22. |
S109-160554
|
[9] |
BOLT-SOCKET
|
|
| 29. |
31YC-11040
|
[1] |
BUSHING-PIN
|
|
| 30. |
31YC-11050
|
[1] |
BUSHING-PIN
|
|
| 31. |
Y000-070200
|
[4] |
SEAL-DUST
|
|
| 23. |
31Y1-03820
|
[2] |
BAND ASSY
|
|
| 23-1. |
31Y1-03830
|
[1] |
BAND SUB ASSY
|
|
| 23-2. |
31YC-31040
|
[1] |
BAND
|
|
| 23-3. |
S011-100352
|
[2] |
BOLT-HEX
|
|
| 23-4. |
S411-100002
|
[2] |
WASHER-SPRING
|
|
| 23-5. |
31YC-36010
|
[1] |
CLAMP-PIPE
|
|
| 23-6. |
S015-120502
|
[1] |
BOLT-HEX
|
|
| 23-7. |
S411-120002
|
[1] |
WASHER-SPRING
|
|
| 24. |
31Y1-18190
|
[1] |
PIPE ASSY
|
|
| 25. |
31Y1-18200
|
[1] |
PIPE ASSY
|
|
| K26. |
S631-026004
|
[2] |
O-RING
|
|
| 27. |
S017-100602
|
[8] |
BOLT-HEX
|
|
| 28. |
S411-100002
|
[8] |
WASHER-SPRING
|
|
| K. |
31Y1-18210
|
[1] |
SEAL KIT
|
|
