凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (0-0A) - SUGGESTED STOCKING GUIDE Case Agriculture
广数供应链运营团队, 18 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
50302
|
[3] |
SPHERICAL BEARING,25.4 mm ID x 52 mm OD x 30.96 mm
|
CAS
Special Superseded by part number: 204807C91, 47577183
|
| . . |
1700145
|
[1] |
COUPLING
|
IH
Draper
|
| . . |
51200380
|
[2] |
FLANGE
|
CAS
Bearing
|
| . . |
50591
|
[4] |
FLANGE,52mm
|
IH
Bearing Superseded by part number: 86548974
|
| . . |
55335
|
[1] |
BELT
|
IH
Drive
|
| . . |
667925R91
|
[1] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
Cam Superseded by part number: 47577176
|
| . . |
700108838
|
[12] |
ROD
|
IH
Blade
|
| . . |
700115850
|
[11] |
SPACER
|
IH
|
| . . |
700117406
|
[15] |
LARGE PLATE
|
IH
PLATE, LARGE
|
| . . |
700118640
|
[7] |
KNIFE
|
IH
Kit, Blade, Rotor (Set of 2 Blades)
|
| . . |
700706779
|
[2] |
SPIDER ASSY.
|
L
Superseded by part number: 84355349
|
| . . |
700707942
|
[4] |
DISC
|
IH
Friction Superseded by part number: 84037045
|
| . . |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
Spherical Superseded by part number: 47577188, 47066
|
| . . |
700709676
|
[1] |
BELT,37.00 mm W
|
CAS
Cog
|
| . . |
700710260
|
[1] |
SEAL KIT
|
CAS
Kit, w/O-Ring
|
| . . |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
Spherical Superseded by part number: 47577203
|
| . . |
825620C1
|
[6] |
RETAINER
|
IH
Bearing
|
| . . |
714360
|
[1] |
FLANGED BEARING
|
IH
Flange
|
| . . |
7713829
|
[1] |
BEARING ASSY,19.56 mm ID x 63.75 mm OD
|
IH
Superseded by part number: 688282
|
| . . |
B17231
|
[1] |
KIT
|
CAS
Seal
|
| . . |
H747188
|
[2] |
FLANGED BEARING,112.73 mm OD x 8.74 mm
|
CAS
Bearing
|
