凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (7-14) - SHIELDS ASSEMBLY, LOWER SIDE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700114084
|
[2] |
STRAP
|
HFI
|
| 2. |
121-115
|
[61] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 3. |
231-5145
|
[67] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT - hex serrated flange, 5/16 inch NC Superseded by part number: 72187067, 145458
|
| 4. |
700131978
|
[1] |
SHIELD
|
HFI
- left
|
| 5. |
700115994
|
[1] |
SUPPORT
|
HFI
WA
|
| 6. |
700116002
|
[1] |
DOOR
|
CAS
- left
|
| 7. |
440-1106
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 3/8"
|
CAS
Superseded by part number: 72181877
|
| 8. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 9. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 10. |
7025075
|
[2] |
BRACKET
|
CAS
|
| 11. |
700115984
|
[4] |
HINGE
|
HFI
WA
|
| 12. |
700116000
|
[1] |
STRAP
|
HFI
- left
|
| 13. |
700115991
|
[1] |
SUPPORT
|
HFI
- jack
|
| 14. |
700117071
|
[1] |
PANEL
|
CAS
- left
|
| 15. |
494307C1
|
[2] |
LATCH
|
IH
HOOK - rubber Superseded by part number: 86975220
|
| 16. |
432-68
|
[2] |
COTTER PIN,3/32" x 1/2"
|
CAS
PIN, SPLIT (COTTER), 3/32" x 1/2" Superseded by part number: 88788
|
| 17. |
776674
|
[2] |
SUPPORT
|
L
ANCHOR
|
| 18. |
141-13
|
[2] |
CLEVIS PIN,1/4" x 1.594"
|
CAS
1/4 X 1-1/2 CLEVIS PIN
|
| 19. |
700115977
|
[1] |
STRAP
|
HFI
|
| 20. |
S120261
|
[2] |
PIN
|
CAS
.148 WIRE HAIR PIN COTTER
|
| 21. |
700117082
|
[2] |
SUPPORT
|
HFI
|
| 22. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 23. |
700117079
|
[2] |
LATCH
|
HFI
- lower
|
| 24. |
700117081
|
[4] |
SPACER
|
HFI
|
| 25. |
700116003
|
[1] |
DOOR
|
CAS
- right
|
| 26. |
7883358
|
[4] |
SCREW,Hex Washer, 5/16" - 18 x 1 1/2"
|
CAS
5/16-18 X 1-1/2 HWHMS Superseded by part number: 163-56
|
| 27. |
700116028
|
[2] |
SUPPORT
|
HFI
|
| 28. |
439-5532
|
[2] |
HEADED PIN,5/16" x 2"
|
CAS
5/16 X 2 CLEVIS PIN
|
| 29. |
700117080
|
[2] |
CHANNEL
|
HFI
|
| 30. |
700117078
|
[2] |
SUPPORT
|
CAS
|
| 31. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 32. |
432-812
|
[2] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 33. |
700115999
|
[3] |
SUPPORT
|
HFI
WA
|
| 34. |
700131973
|
[1] |
SHIELD
|
HFI
- right
|
| 35. |
700117083
|
[2] |
STRAP
|
HFI
|
| 36. |
700115986
|
[4] |
HINGE
|
HFI
WA
|
| 37. |
700116001
|
[1] |
STRAP
|
HFI
- right
|
| 38. |
121-108
|
[2] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
