现代零件查询R140W-7 OUTRIGGER MOUNTING(FRONT)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N1. |
51N4-54000
|
[1] |
OUTRIGGER ASSY-FRONT
|
|
| N1. |
51N4-54001
|
[1] |
OUTRIGGER ASSY-FRONT
|
|
| 1-1. |
51N4-54010
|
[1] |
FRAME WA-FRONT O/R
|
|
| 1-1. |
51N4-54011
|
[1] |
FRAME WA-FRONT O/R
|
|
| 1-2. |
51N4-53200
|
[2] |
LEG ASSY
|
|
| 1-2-1. |
51N4-53210
|
[1] |
LEG WA
|
|
| 1-2-2. |
51EK-52550
|
[4] |
BUSHING
|
|
| 1-2-3. |
S700-070206
|
[4] |
DUST SEAL-DKIY TYPE
|
|
| 1-2-4. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
| 1-3. |
51N4-53300
|
[2] |
FOOT WA
|
|
| 1-4. |
51N4-55510
|
[2] |
PIN ASSY
|
|
| 1-4. |
51N4-55511
|
[2] |
PIN ASSY
|
|
| 1-5. |
51N4-55520
|
[2] |
PIN ASSY
|
|
| 1-6. |
51EK-52542
|
[2] |
PIN-SAFETY
|
|
| 1-6. |
51EK-52542BG
|
[2] |
PIN-SAFETY
|
|
| 1-7. |
S391-070120
|
[4] |
SHIM-ROUND(1.0T)
|
|
| 1-8. |
S461-800902
|
[4] |
PIN-SPLIT
|
|
| 1-8. |
S461-800902
|
[2] |
PIN-SPLIT
|
|
| 1-9. |
51N4-53100
|
[2] |
LEG & FOOT ASSY
|
|
| 1-9-1. |
51N4-53200
|
[1] |
LEG ASSY
|
|
| 1-9-11. |
51N4-53210
|
[1] |
LEG WA
|
|
| 1-9-12. |
51EK-52550
|
[4] |
BUSHING
|
|
| 1-9-13. |
S700-070206
|
[4] |
DUST SEAL-DKIY TYPE
|
|
| 1-9-14. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
| 1-9-2. |
51N4-53300
|
[1] |
FOOT WA
|
|
| 1-9-3. |
51N4-55520
|
[1] |
PIN ASSY
|
|
| 1-9-3. |
51N4-55521
|
[1] |
PIN ASSY
|
|
| 1-9-4. |
S461-800902
|
[1] |
PIN-SPLIT
|
|
| 2. |
51N4-55530
|
[2] |
PIN ASSY
|
|
| 2. |
51N4-55531
|
[2] |
PIN ASSY
|
|
| 3. |
51N4-55540
|
[2] |
PIN ASSY
|
|
| 3. |
51N4-55541
|
[2] |
PIN ASSY
|
|
| 4. |
51EK-52570
|
[1] |
PLATE-COVER
|
|
| 5. |
51E4-2712
|
[1] |
COVER
|
|
| 6. |
51EK-52990
|
[2] |
REFLECTOR-REAR
|
|
| 7. |
S018-240502
|
[16] |
BOLT-HEX
|
|
| 8. |
S037-122552
|
[8] |
BOLT-W/WASHER
|
|
| 9. |
S441-240002
|
[16] |
WASHER-HARDENED
|
|
| 10. |
S391-070130
|
[8] |
SHIM-ROUND(1.0T)
|
|
| 11. |
S461-800902
|
[4] |
PIN-SPLIT
|
|
| 12. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
