Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
1. | 14M7167 | [6] | Lock Nut | M10 |
2. | 14M7166 | [2] | Lock Nut | M8 |
3. | W12243 | [2] | Pressed Flanged Housing | |
4. | JD10422 | [1] | Bearing | (SUB JD9218 AND JD9217) |
5. | RE28751 | [1] | Retainer | (SUB W12243 AND W40244) |
6. | 03M7184 | [2] | Bolt | M8 X 20 |
7. | RE30858 | [1] | Support | |
8. | 19M7181 | [2] | Cap Screw | M10 X 55 |
9. | 19M7358 | [3] | Cap Screw | M10 X 40 |
10. | 24H1309 | [4] | Washer | 13/32" X 1-1/16" X 0.120" |
11. | W40244 | [1] | Strap | NLA |
12. | 19M7938 | [1] | Cap Screw | M10 X 20 |
