Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
1. | 19M7300 | [4] | Cap Screw | M6 X 10 |
2. | R91184 | [1] | Screen | |
3. | M78941 | [1] | Housing | (SUB FOR R91181) |
4. | R88207 | [1] | Cover | |
5. | 19M7881 | [1] | Screw | M8 X 20 |
6. | R91827 | [1] | Bolt | |
7. | 14M7166 | [2] | Lock Nut | M8 |
8. | RE31584 | [1] | Bracket | (SUB R88578 AND 19M7162) |
9. | 24M7207 | [2] | Washer | 8.400 X 24 X 2 MM |
10. | 14M7166 | [1] | Lock Nut | M8 |
11. | 24M7095 | [4] | Washer | 8.400 X 15 X 1.600 MM |
12. | 19M7932 | [4] | Cap Screw | M8 X 16 |
13. | R88578 | [1] | Angle | |
14. | 19M7162 | [1] | Cap Screw | M8 X 16 |
