纽荷兰零件查询(D46) - DRIVE AXLE PCG (1/88-) (003) - CENTER HOUSING ASSY. W/DIFFERENTIAL AND RELATED PARTS New Holland Constructuion_纽荷兰New Holland_工程机械

Pos.	Part No	Qty	Parts name	Comments
1.	81803474	[1]	SNAP RING,2.37" ID	BASRING, SNAP, 2.37" ID
2.	81800475	[1]	WASHER,64.64mm ID x 78.74mm OD x 3.25mm Thk	FOR
3.	F1NN4N064AA	[1]	COUPLING,27 T	FOR Superseded by part number: 81871527
4.	81800474	[1]	SPRING	FOR
5.	81800472	[1]	ADAPTER	BASAdaptor
6.	81803420	[1]	BEARING CUP,158.75mm OD x 15.88mm W	BASCup, Roller Bearing
7.	81803413	[1]	ROLLER BEARING,107.95mm ID x 21.44mm W	WINBEARING, ROLLER, TAPERED, Assy, Cone & Roller, Rear Axle, Differential
8.	83994579	[8]	LOCK BOLT,1/2" - 13 x 2-7/8", Gr 8	BASBOLT, LOCK, Hex, 1/2"-13 x 2 7/8", G8
9.	E7NN4204AA	[1]	SUMP	BASCase Assy., 3.1
9.	81816246	[1]	HOUSING	BASCase Assy., 3.50, 3.91, 4.11, 4.625
9.	81816247	[1]	HOUSING	FORAssy, 5.286, 6.667
10.	81800471	[2]	BUSHING,72.08mm ID x 75.21mm OD x 31.75mm L	WIN
11.	81803424	[2]	THRUST WASHER,76.2mm ID x 101.6mm OD x 1.58mm Thk	BASWasher
12.	81803451	[1]	GEAR,27 Teeth	BAS16T
13.	81876885	[1]	SPIDER,28.4mm Cap Dia, 179.3mm L	WIN
14.	81728114	[4]	PINION,9 Teeth	BAS
15.	83989915	[4]	THRUST WASHER,1" x 2" x .060" Thk	WINWASHER, THRUST, 1" x 2" x .060" Thk
16.	81803445	[1]	GEAR,38 Teeth	BAS
17.	F0NN4209FA	[1]	RING GEAR	BASGear Set, Matched, 3.1, 10 x 31T (40V03) Superseded by part number: 81866332
17.	81847145	[1]	GEAR SET	FORMatched, 3.50, 10 x 35T
17.	81874460	[1]	GEAR SET	BASMatched, 3.91, 11 x 43T (40V04)
17.	83958890	[1]	GEAR SET	BASMatched, 4.11, 9 x 37T (40V05)
17.	E2NN4209DA	[1]	GEAR SET	BASMatched, 4.625, 8 x 37T (40V06) Superseded by part number: 83937179
17.	D3NN3222A	[1]	GEAR SET	WINMatched, 5.286 Superseded by part number: 81834018
17.	E2NN4209CA	[1]	GEAR SET	BASMatched, 6.667
18.	510884	[1]	ROLLER BEARING,66.69mm ID x 30.05mm W	WINCone
19.	510892	[1]	BEARING CUP,112.71mm OD x 23.81mm W	GICup, Roller Bearing
20.	83957533	[12]	SCREW,Pan HD, 1/2" - 20 x 1-5/8", Gr 8	WINBOLT, , G8 1/2"-20 x 1.62"
21.	83417169	[12]	NUT,1/2"-20, GA	BASNUT, LOCK, 1/2"-20, GA
22.	9706729	[2]	BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd	NH
23.	81547	[1]	BEARING WASHER,7/16"	NHWASHER, LOCK, 7/16"
24.	82852466	[1]	BLOCK	BASThrust, 3.1
24.	81803369	[1]	BLOCK	BASThrust, 3.50, 3.91, 4.11, 4.625
24.	81803368	[1]	BLOCK	FORThrust, 5.286, 6.667
25.	263136	[2]	MAGNETIC PLUG,Sq. Soc, 3/4"-14 NPTF	NHPLUG, MAGNETIC, Sq. Soc, 3/4"-14 NPTF
26.	83955462	[1]	HOUSING	FORCW
26.	86517774	[1]	HOUSING	IMOCCW
27.	21T4022	[1]	BREATHER	GIBreather
28.	81803542	[1]	RING,1.186" ID	BAS
29.	81824478	[1]	BEARING ASSY,30mm ID x 62mm OD x 19.05mm W	WINBearing Assy.
30.	513368	[1]	ROLLER BEARING,44.45mm ID x 28.57mm W	WINCone
31.	81847146	[1]	RETAINER	FORAssy. Includes: Ref. 32 & 33
32.	513369	[1]	BEARING CUP,95.25mm OD x 22.23mm W	WINBearing, Cup
33.	81812385	[1]	BEARING ASSY,88.92mm OD x 23.07mm W	PABEARING, CUP
34.	81847148	[1]	SPACER	BAS1.2540" - 1.2545"
34.	81847149	[1]	SPACER	BAS1.2560" - 1.2565"
34.	81847150	[1]	SPACER	BAS1.2580" - 1.2585"
34.	81847151	[1]	SPACER	BAS1.2600" - 1.2605"
34.	81847152	[1]	SPACER	BAS1.2620" - 1.2625"
34.	81847153	[1]	SPACER	BAS1.2640" - 1.2645"
34.	81847154	[1]	SPACER	BAS1.2660" - 1.2665"
34.	81847155	[1]	SPACER	BAS1.2680" - 1.2685"
34.	81847156	[1]	SPACER	BAS1.2700" - 1.2705"
34.	81847157	[1]	SPACER	FOR1.2720" - 1.2725"
34.	81847158	[1]	SPACER	BAS1.2740" - 1.2745"
34.	81847159	[1]	SPACER	FOR1.2760" - 1.2765"
34.	81847160	[1]	SPACER	BAS1.2780" - 1.2785"
34.	81847161	[1]	SPACER	BAS1.2800" - 1.2805"
34.	81847162	[1]	SPACER	BAS1.2820" - 1.2825"
35.	81827354	[1]	O-RING,0.139" Thk x 4.609" ID, -247, Cl 5, 75 Duro	BAS4 5/8" ID x .139" Thk
36.	80280248	[6]	LOCK WASHER	IMOWASHER, LOCK, 9/16"
37.	88702	[6]	BOLT,Hex, 9/16" x 1 1/2", Gr 5, Full Thd	PAScrew, Cap, HH, G5, 9/16"-12 x 1-1/2"
38.	81845711	[1]	BEARING ASSY	BASBEARING, CONE Superseded by part number: 298194R91
39.	81845713	[1]	SEAL	WIN
40.	81834073	[1]	OIL SEAL,66.67mm ID x 89.03mm OD x 11mm Thk	WINSeal Assy.
41.	83912246	[1]	RETAINER	FOR
42.	83949810	[1]	FLANGE	WINU-Joint, 1410 With Tapped Holes
42.	85805307	[1]	BRAKE DISC,220mm OD	IMOFlange, U-Joint, for Handbrake
42.	E7NN4858AA	[1]	FLANGE	BASU-Joint, 1480 W/Mounting Surface for Handbrake Disc, 40V03, 40V04
42.	86513686	[1]	FLANGE	BASU-Joint, Handbrake Disc, 40V05 and 40V06
43.	81845714	[1]	SEAL	WIN
44.	D1NN4N118A	[1]	WASHER	FOR Superseded by part number: 81847144
45.	D3NN4320A	[1]	NUT	FOR1 1/4 - 18
46.	PL	[1]	PROCURE LOCALLY	BASCotter, 3/16" x 2-1/8"
47.	81803515	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.02mm Thk	BASDiff. Bearing, LH 3.80" x 4.40" x .038/.040" Thk
47.	81803516	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.17mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .044/.046" Thk
47.	81803517	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.32mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .050/.052" Thk
47.	81803518	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.47mm Thk	BAS3.80" x 4.40" x .056/.058" Thk, Differential Bearing, LH
47.	81803519	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.63mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .062/.064" Thk
47.	81803520	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.78mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .068/.070" Thk
47.	81803521	[1]	SHIM,96.52mm ID x 111.76mm OD x 1.93mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .074/.076" Thk
47.	81803522	[1]	SHIM,96.52mm ID x 111.76mm OD x 2.08mm Thk	BASDifferential Bearing, LH 3.80" x 4.40" x .080/.082" Thk
