Pos. | Part No | Qty | Parts name | Comments |
---|---|---|---|---|
1. | AW26798 | [1] | Kit | (QUIET MUFFLER KIT INCLUDES INSTALLATION INSTRUCTIONS) |
2. | M121981 | [1] | Gasket | NLA; SUB FOR PT14137 |
3. | 03M7188 | [2] | Bolt | M8 X 40 |
4. | 14M7166 | [2] | Lock Nut | M8 |
5. | 24M7055 | [2] | Washer | 8.400 X 16 X 1.600 MM |
6. | R59468 | [1] | Spring | |
7. | W40356 | [1] | Angle | |
8. | 37H228 | [1] | Screw | |
9. | AW26849 | [1] | Arrestor | |
10. | AW26848 | [1] | Spark Arresting Muffler | |
11. | W40385 | [1] | Plate | |
12. | 24H1283 | [4] | Washer | 7/32" X 1/2" X 0.049" |
13. | R55326 | [4] | Rivet | |
14. | 14M7273 | [2] | Nut | M8 |
15. | 12H303 | [2] | Lock Washer | 5/16" |
16. | M68144 | [2] | Stud | NLA; ORDER MIU11949 |
