| 1. |
ZA105892
|
[1] |
CONTROL
|
CAS
BOX ASSEMBLY - control
|
| 2. |
1261437C1
|
[1] |
LAMP
|
CAS
BULB - lamp, no. 37
|
| 3. |
131181C1
|
[1] |
RELAY
|
IH
- control box Superseded by part number: 3221235R2
|
| 4. |
ZA734450
|
[1] |
HANDLE
|
IH
- toggle switch
|
| 5. |
17175R1
|
[1] |
LOCK PIN,3/16" x 1", Slotted
|
IH
PIN, 3/16" x 1", Slotted Superseded by part number: 118827
|
| . . |
ZA103773
|
[1] |
PACKAGE
|
IH
KIT - mounting, control box
|
| 8. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
KNOB - mounting
|
| 9. |
179454C1
|
[2] |
RUBBER WASHER
|
IH
- rubber
|
| 10. |
495-21031
|
[4] |
WASHER,1/4"
|
CAS
- flat, 5/16 x 47/64 x 3/64 inch (8 x 19 x 1 MM) Superseded by part number: 80701, 72187262
|
| 11. |
ZA105277
|
[1] |
BRACKET
|
IH
- mounting
|
| 15. |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 12. |
1261522C91
|
[1] |
BRACKET, SUPPORTING
|
IH
BRACKET ASSEMBLY - cab mounting
|
| 13. |
598802R1
|
[4] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G5, Full Thd
|
IH
BOLT - round head square neck, 5/16 NC x 3/4 inch Superseded by part number: 280497
|
| 14. |
116120
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 83990583, 322358
|
| 17. |
ZA104615
|
[1] |
HARNESS
|
IH
- tractor
|
| 18. |
ZA104616
|
[1] |
HARNESS
|
IH
- control box
|
| 19. |
ZA105525
|
[1] |
HARNESS
|
CAS
- baler
|
| 20. |
ZA103745
|
[1] |
HARNESS
|
IH
- extension
|
| 21. |
ZA105270
|
[1] |
HARNESS
|
IH
KIT - harness, emergency (For temporary operation of actuator) (Also order switch 91774C1)
|
| 22. |
91774C1
|
[1] |
ASSEMBLY
|
IH
SWITCH - toggle, double pole double throw, momentary
|
| 23. |
REF
|
[1] |
INSTRUCTION
|
NH
ACTUATOR - twine tube (See page 4)
|
| 24. |
ZA103633
|
[1] |
SWITCH
|
IH
- bale density Superseded by part number: 232773A1
|
| 25. |
ZA104562
|
[1] |
COVER
|
IH
ASSEMBLY - switch Superseded by part number: 230414A1
|
| 26. |
120221
|
[4] |
NUT,Sl Rnd Hd, #10 - 24 x 1/2"
|
IH
SCREW - round head slotted, no. 10 NC x 1/2 inch Superseded by part number: 159920
|
| 27. |
221431
|
[2] |
WASHER - flat, 5/32 x 1/32 inch (4 x 10 x 1 MM)
|
|
| 28. |
120217
|
[4] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 29. |
26303R1
|
[4] |
HARDWARE,#10-24
|
IH
NUT - hex, no.10 NC Superseded by part number: 3062835R1
|
| 30. |
ZA104394
|
[1] |
BUSHING
|
IH
- strain relief
|
| 31. |
169851C1
|
[1] |
GROMMET
|
IH
BUSHING - strain relief
|
| 32. |
299407C1
|
[4] |
CLAMP
|
IH
- tube Superseded by part number: 86010402
|
| 33. |
299404C1
|
[8] |
CLAMP
|
IH
- tube Superseded by part number: 86572009
|
| 34. |
533959R1
|
[1] |
CABLE TIE,.135" x 11"
|
IH
STRAP - tie Superseded by part number: 529070
|
| . . |
ZA105438
|
[1] |
KIT
|
CAS
- connector
|
| 35. |
245430C1
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR - male, 8 terminal Superseded by part number: 87698229
|
| 36. |
3195530R1
|
[1] |
CONNECTOR, ELEC
|
CAS
CONNECTOR - female, 8 terminal
|
| 37. |
877291R1
|
[1] |
ELEC CONNECTOR,Female
|
IH
CONNECTOR - male, 2 terminal Superseded by part number: 87693325
|
| 38. |
872290R1
|
[1] |
ELEC CONNECTOR,Male
|
IH
CONNECTOR - fe, 2 terminal Male Superseded by part number: 87697530
|
| . . |
739145C1
|
[10] |
ELEC. TERMINAL PIN,Male, 3 - 5 mm2
|
IH
TERMINAL - male (Not shown) Superseded by part number: 87697669
|
| . . |
739067C1
|
[10] |
TERMINAL CONNECTOR,Female, 5 mm2
|
CAS
TERMINAL - female (Not shown) Superseded by part number: 87703293
|
| 39. |
ZA104561
|
[1] |
BRACKET
|
IH
- switch
|
| 40. |
120391
|
[2] |
WASHER,#10
|
IH
- flat, 7/32 x 1/2 x 1/32 inch (6 x 13 x 1 MM) Superseded by part number: 9824326
|
| 41. |
488837C1
|
[1] |
SPRING NUT
|
IH
- speed, U type, 5/16 inch
|
